High pressure cleaning technology, parts washers, tire cleaners, high speed

• Triple bearing system
• Seal failure warning, through weep holes
• Stainless steel
• Maintenance free
• Carbide seals

G1 1/4”NPTF, G2 1/4”NPTM, NW 1/4”, SW1 0.87, SW2 0.67, L1 3.25, L2 0.43, D1 0.98, Weight 7.5 oz

Technical data

• Pressure: 4000 psi(27.5 MPa)
• Temperature: 250 °F (max. 2’000 rpm)
• RPM: max. 2’000 rpm)
• Body: DYL: brass, nickel plated, SYLI: Stainless steel
• Inner part: Stainless steel
• Seal: carbide
• Bearing: 2x radial ball bearings, 1x thrust ball bearing
• Throughput: pH 3-12
• Medium: filtered 10 microns, compressed air (290 psi)
