Product Details
＋
Fastron Electronics GT-DVO(0-75mV)D1, Signal Conditioner/Isolator/Voltage Transducer, 0-75mVDC input, 22-60VAC/DC aux, 4-20mA output
- Program control, converter function are standard features
- 5-digit displays suit most industries including Temperature, Humidity, Pressure (0.5s response)
- Drip-proof / Dust-proof IP66 (front panel only)
- 9-step pattern (for SV and time) is a standard feature
- UL/CSA Approved
- Input signals can be converted to insulated 4 to 20 mA DC output (for direct current output type)
- Each unit needs just 60 mm depth panel space
Specification
| Fastron Electronics Part Number | GTD-DVO(0-75mV)D1 |
| Control Output | 4 - 20mA |
| Input | 0 - 75mVDC |
| Over Range | x 1.5 |
| Operating Temperature | 0 - 60°C |
| Load Voltage | 22 - 60VDC |
| Span Adjustment Range | /-10% |
| Zero Adjustment Range | /-5% |
| Termination Style | Screw |
| Mounting Style | DIN Rail Mount |
| Case Material | PC - UL 94 V0 |
| Weight | 170g |
| Factory Pack Qty | 1 |
